PET THERMAL LAMINATING FILM

We manufacture various types of PET thermal lamination films to our worldwide customers and our PET thermal laminating films mainly fall into following categories:

  • PET Transparent thermal lamination film
  • PET Metalized thermal lamination film
  • PET Holographic thermal lamination film

PET thermal laminating films are used to get some properties which are available in polyester. Some main properties like high gloss and high stiffness are not in BOPP films. For making PET thermal laminating films we need to follow coextrusion process.
Wide varieties of PET Thermal laminating film are available in the market. PET dry lamination films are in wide range of thickness like 0.9 mil to 10 mil (22 micron to 250 micron) with comparison to BOPP lamination films. Since density of PET is 1.4 g/mt2 and we get less yield (kgs/area) than other lower density films.

  thickness(mic) ration/yield resistance
silver/gold Totalthickness hicknesstolerance M2/MT G/25MM
24 +/-1.5MIC 27.6 560
width 200mm-1860mm (±5mm)
length 200m-9000m
paper core 76mm (3″)and 25.4mm(1″)
connector ≤2
corona treatment double side
surface tension PET side≥42 dyne EVA side≥52 dyne

Features of PET thermal lamination films

PET dry lamination is done on costly brochures and some basic properties of this kind of laminating films are as follows.

  • High gloss
  • High stiffness
  • High bond strength
  • Hot stamping
  • UV coating on surface
  • High tensile strength

Applications of PET thermal laminating films

Properties of PET thermal laminating films made it so useful to convert into a growing lamination market. Applications of this film are increasing each day. Some main applications are as follows.

  • Costly brochures
  • Catalogues
  • Menu cards
  • Mark sheets
  • Maps
  • Publicity material
